Omron E5EWL-R1TC Digital Temperature Controller 100-240VAC
$80.00
The Omron E5EWL-R1TC is a compact 1/32 DIN digital temperature controller from Omron's E5EWL series. Featuring PID auto-tuning, thermocouple input, and relay output, it delivers precise temperature regulation in a space-saving form factor — ideal for industrial ovens, packaging machines, plastic molding equipment, food processing, and HVAC applications. Simple front-panel programming and a bright LED display make setup fast even in demanding environments.
- Brand: Omron
- Series: E5EWL
- Part Number: E5EWL-R1TC
- Type: Digital PID Temperature Controller
- Condition: New
Technical Specifications
| Specification | Value |
|---|---|
| Size | 1/32 DIN (48 x 24 mm panel cutout) |
| Supply Voltage | 100–240 VAC, 50/60 Hz |
| Power Consumption | Max. 4 VA |
| Input Type | Thermocouple (TC) |
| Thermocouple Types Supported | K, J, T, E, L, U, N, R, S, B, W, PL-II |
| Temperature Range | -200°C to +1300°C (depends on TC type) |
| Display | 4-digit LED (process value & set point) |
| Control Method | PID / ON-OFF (auto-tuning) |
| Output Type | Relay output (SPST-NO, 250 VAC / 3A) |
| Control Output | 1 output (heating or cooling) |
| Alarm Outputs | None (standard model) |
| Setting Method | Front-panel keys |
| Sampling Period | 500 ms |
| Insulation Resistance | 20 MΩ min. (500 VDC) |
| Dielectric Strength | 2,000 VAC 50/60 Hz for 1 min |
| Operating Temperature | -10°C to +55°C |
| Storage Temperature | -25°C to +65°C |
| Operating Humidity | 35–85% RH (non-condensing) |
| Protection Rating | IP50 (front panel) |
| Dimensions (W x H x D) | 48 x 24 x 78 mm |
| Weight | Approx. 100 g |
| Certifications | CE, UL, cUL, KC |
